Diesel & Petrol Engine Hydraulic Power Pack
We are Mega Industrial Equip & Machines Manufacturing LLC the largest Manufacturer of Diesel engine / Petrol Engine / Electric Power hydraulic power unit manufacturing for Marine Applications ZONE-II certified unit and supplying spare parts as well like Starter, Filters, Engine, pressure relief valves, piston pump, vane pump, gear pump, Engine Accessories, Tank, etc…
Diesel Engine Hydraulic power unit is often used in Marine/construction / agricultural applications where electric power is not available at the site. Diesel-hydraulic units offer a versatile and portable power source for these applications.
The Diesel-hydraulic power packs can be delivered with an ATEX certificate offshore applications. This is necessary when you are pumping in potentially explosive environments. Our power packs are available in various designs and with several capacities from low flow rate to high flow rate & Low pressure to High-pressure Units. The Diesel Engine power pack is built with necessary components with a Hose Basket as well.
Diesel Engine hydraulic units may have several Electrical or Manual Directional control valves that allow the operator to direct the flow of hydraulic fluid to the various components of the system. The control valves may be operated manually or Electrical control panel. Electrical directional valves can be used in this unit except Zone II application
Specification of Diesel Engine / Petrol Engine HYDRAULIC POWER UNIT The Diesel Engine driven power unit has a Hydraulic Piston Pump /Gear Pump or Vane Pump with a flow output of 6 LPM to 400LPM @1800 RPM with a maximum pressure of 4350 PSI to achieve the cylinders raise & lower operations under designed load conditions.
Specification of Diesel Engine / Petrol Engine HYDRAULIC POWER UNIT The engine Capacity has a minimum rating of 5HP to Max. 173HP with water or air-cooled engine which is from Deutz, JCB, or FPT engines.
The power unit consists of the following items:
• Painted or Sandblasting with Powder coated structural skid
• Engine – Petrol or Diesel
• Electrical Motor
• Pump
• Hydraulic tank with all accessories
• Diesel reservoir with all accessories
• Pilot-operated relief valve for controlling the max pressure of the system.
• Control Panel with control for accelerator, pressure gauge, Temperature gauge, Tachometer, Oil Pressure gauge, Emergency Engine shut down knob, Engine Control & Monitoring unit & controlling the engine parameters during operation.
• Power source: Starter
• All metal components are grit blasted, primed with two-pack epoxy primer, and finished with heavy-duty, two-pack epoxy polyamine industrial coatings.
Mega Industrial Equipment is the stockiest / Distributor of CONTARINI Hydraulic components, CAPRONI, OMT, B&C HYDRAULICS, M+S HYDRAULICS,
POLY-HYDRON, WINNER HYDRAULICS, HYDROLINE PRODUCTS which will be used in this Diesel Engine hydraulic power unit.
Available Options:
• Custom-designed unit suitable for specific required capacity and Applications
• Proportional or non-proportional directional control valve with pressure relief valve
• Air blast oil cooler / Hydraulic Motor driven fan of electric motor
• Fully lockable cabinet
• Power isolation lockout switch,
• Soft starter (electric motor)
• Bunded base.
• Custom-designed hydraulic manifold to suit a range of actuators,
• Wireless pendant control.
Mega Industrial Equipments making all our diesel engine Hydraulic power units comes with 12-month warranty from the invoice date, to ensure that your system component will enjoy a long and productive lifetime
Diesel Engine
Petrol Engine
1. Do you supply diesel and petrol engine hydraulic power packs in Dubai, UAE?
Yes. Mega Industrial Equip & Machines Manufacturing L.L.C. is a leading manufacturer and supplier of diesel, petrol, and electric power hydraulic power units for marine and industrial applications across the UAE.
2. When would I choose a diesel-hydraulic power pack over an electric one?
Diesel-hydraulic power packs are used for marine, construction, and agricultural applications where electric power isn’t available on site, offering a versatile, portable power source.
3. What flow rate and pressure do your diesel/petrol engine power units support?
The hydraulic piston, gear, or vane pump delivers 6 to 400 LPM at 1,800 RPM, with a maximum pressure of 4,350 PSI for cylinder raise and lower operations under design load.
4. What engine capacities are available?
Engine capacity ranges from a minimum of 5 HP up to 173 HP, with water- or air-cooled engines from Deutz, JCB, or FPT.
5. Are these power packs certified for use in explosive or offshore environments?
Yes. Our diesel engine unit is ZONE-II certified, and units can be delivered with an ATEX certificate for offshore applications where potentially explosive environments require it.
6. What's included in a standard diesel/petrol engine power unit?
A painted or sandblasted, powder-coated structural skid, petrol or diesel engine, electrical motor, pump, hydraulic tank with accessories, diesel reservoir with accessories, pilot-operated relief valve, and a control panel with accelerator, pressure gauge, temperature gauge, tachometer, oil pressure gauge, and emergency shutdown.
7. Can the directional control valves be operated manually or electrically?
Yes. Units can be fitted with manual or electrical directional control valves, though electrical valves aren’t used in Zone II certified applications.
8. Do you supply spare parts for diesel and petrol engine power units?
Yes — starters, filters, engines, pressure relief valves, piston pumps, vane pumps, gear pumps, engine accessories, and tanks are all available as spare parts.
9. Which hydraulic component brands do you stock for these power units?
We stock and distribute CONTARINI, CAPRONI, OMT, B&C HYDRAULICS, M+S HYDRAULICS, POLY-HYDRON, WINNER HYDRAULICS, and HYDROLINE PRODUCTS.
10. Can these power units be custom designed for my application?
Yes. Custom-designed units are available to match specific capacity and application requirements, including custom hydraulic manifolds for a range of actuators.
11. What optional features can be added to a diesel/petrol engine power pack?
Proportional or non-proportional directional control valves, an air blast oil cooler or hydraulic motor-driven fan, a fully lockable cabinet, power isolation lockout switch, soft starter, bunded base, and wireless pendant control.
12. How are the metal components finished for corrosion protection?
All metal components are grit blasted, primed with two-pack epoxy primer, and finished with heavy-duty two-pack epoxy polyamine industrial coatings.
13. Do you offer a warranty on diesel engine hydraulic power units?
Yes. Every diesel engine hydraulic power unit comes with a 12-month warranty from the invoice date.
14. Which industries typically use diesel or petrol engine hydraulic power packs?
Marine, construction, and agricultural industries, particularly for applications where electric power isn’t available on site.
